Single Stage Side Channel Blower
Overview
SC Series single-stage side channel blowers provide reliable, oil-free air movement for both vacuum and low-pressure applications. Their contact-free operating principle eliminates the need for lubrication in the compression chamber, helping to provide clean, low-maintenance operation. The blowers can be installed horizontally or vertically and are suitable for a wide range of industrial applications.
The single stage side channel blower does not need any lubrication because there is no contact between the static and the rotating components and bearings are permanently prelubricated. Blowers can work vertically and horizontally as well while working in compression as in suction.
The devices are manufactured according to the following norms: EN2006/42, EN ISO 12100;2010, EN 60204-1:2006+AC:2010, EN2014/35 e EN2014/30 and according to the following ones EN-61000-64:2007 and EN61000-6-2:2005, compliant to 2004/108/CE norm.
The complete range is UL certified. Certificate number QDGS2.E497559
We tick all the boxes:
Models
Technical Features
Side Channel blowers and exhausters – standard version
The standard series has the following features:
- Housing and impellers in die-cast aluminium alloy
- Asynchronous, multi-voltage and multi-frequency motors with the following characteristics:
- Die-cast aluminium alloy housing and impellers
- Asynchronous, multi-voltage and multi-frequency motors
- NSK bearings
- TP thermal protection
- Suitable for inverter/variable-speed operation
- IE2 efficiency class
- RAL 9006 painted finish
Motor Efficiencies
Main applications fields:
| Application / Industry | Typical Use of Side Channel Blower |
|---|---|
| Pneumatic Conveying (Vacuum or Pressure) | Conveying powders, granules, pellets, lightweight materials via positive pressure or suction. |
| Aquaculture / Fish Farming | Aeration of tanks and ponds; supplying oxygen-rich air for fish, shrimp, and hatchery systems. |
| Wastewater Treatment / Environmental | Aeration of treatment basins, lagoons, and small-scale biological reactors; air agitation. |
| Food & Beverage | Ingredient conveying (flour, grains, sugar), air knives for drying, conveying packaging materials. |
| Packaging Machinery | Vacuum hold-down, product lifting, bag inflation, trimming scrap removal, and blow-off. |
| Printing / Paper Industry | Sheet separation, vacuum feeding, drying ink or coatings, paper conveying. |
| Electronics / Clean Manufacturing | Dust removal, component cooling, air knives for cleaning surfaces without oil contamination. |
| Medical / Laboratory / Dental | Small-scale suction, air agitation, vacuum forming, drying devices, fume extraction. |
| Plastics & Rubber | Granule conveying, mold ventilation, cooling of components, air agitation in dryers. |
| General Industrial Applications | Air knives, vacuum lifting, gas transfer, cooling, drying, agitation, low-pressure aeration. |
